70CM 5 BURNER GAS ON GLASS HOB
WRGOGH70
Drawing 1
Drawing 1 | Item# | Part Details | Availability | £ | |
|---|---|---|---|---|
| Drawing 1 | ||||
| 1 | 1.06.03.05.0024
BURNER CAP (WAS 1.6.2340022-TH) | In Stock | 8.99 | |
| 2 | 1.02.03.10.0010
JUNCTION BOX - COVER | In Stock | 3.99 | |
| 3 | 1.04.03.03.0033
IGNITION ELECTRODE - 400MM (WAS 3.3.1100550) | In Stock | 11.99 | |
| 4 | 1.06.03.06.0048
NOZZLE - NG - 0.98 (WAS 1.8.2010098) | In Stock | 3.99 | |
| 5 | 1.06.03.03.0012
THE END OF THE NO. 3 CUP | In Stock | 10.99 | |
| 6 | 1.04.03.04.0039
THERMOCOUPLE - 250MM (WAS 3.3.1100250) | In Stock | 13.99 | |
| 7 | 1.01.03.03.0049
SEMI-RAPID WATER TRAY | In Stock | 8.99 | |
| 8 | 1.10.03.04.0007
GASKET | In Stock | 8.99 | |
| 9 | 1.06.03.05.0030
BURNER CAP (WAS 1.6.2440022-TH) | In Stock | 8.99 | |
| 10 | 1.06.03.04.0015
FLAME SPREADER (WAS 1.6.2420215-TH) | In Stock | 12.99 | |
| 11 | 1.04.03.03.0030
IGNITION ELECTRODE - 250MM (WAS 3.3.1000250) | In Stock | 12.99 | |
| 12 | 1.04.03.04.0044
THERMOCOUPLE - 550MM (3.3.1100550) | In Stock | 13.99 | |
| 13 | 1.06.03.06.0043
NOZZLE - NG - 0.74 (WAS 1.8.2010074) | In Stock | 4.99 | |
| 14 | 1.06.03.03.0017
END OF 4 CUPS | In Stock | 10.99 | |
| 15 | 1.01.03.03.0059
AUX WATER TRAY | In Stock | 8.99 | |
| 16 | 1.01.03.04.0008
THE VALVE BODY STENTS | Not Available | ||
| 17 | 1.06.03.01.0013
7352 GLASS INTAKE PIPE | Not Available | ||
| 18 | 2.03.03.02.0066
SAFETY VALVE 0.72/NG (WAS 1.7.1152603-TT) | In Stock | 19.99 | |
| 19 | 2.03.03.02.0065
SAFETY VALVE - 0.65/NG (WAS 1.7.1152602-TT) | In Stock | 19.99 | |
| 20 | 2.03.03.02.0068
SAFETY VALVE - 0.99/NG (WAS 171152605TT) | In Stock | 19.99 | |
| 21 | 2.03.03.02.0067
SAFETY VALVE 0.85/NG (WAS 1.7.1152604) | In Stock | Contact Us | |
| 22 | 1.02.03.01.0004
KNOB | In Stock | 5.99 | |
| 23 | 1.06.03.02.0047
7352 ALUMINUM TUBE LOWER LEFT | Low Stock | Contact Us | |
| 24 | 1.06.03.02.0048
7352 UPPER LEFT ALUMINUM TUBE | Low Stock | Contact Us | |
| 25 | 1.06.03.02.0049
7352 ALUMINUM PIPE MIDDLE | Low Stock | Contact Us | |
| 26 | 1.06.03.02.0050
7352 ALUMINUM TUBE UPPER RIGHT | Low Stock | Contact Us | |
| 27 | 1.06.03.02.0051
7352 ALUMINUM TUBE LOWER RIGHT | Low Stock | Contact Us | |
| 28 | 1.06.03.05.0019
RAPID BURNER CAP (WAS 1.6.224022-TH) | In Stock | 10.99 | |
| 29 | 1.06.03.03.0010
BURNER CUP | In Stock | 7.99 | |
| 30 | 1.06.03.06.0051
NOZZLE - NG - 1.24 (WAS 1.8.2010124) | In Stock | 3.99 | |
| 31 | 1.04.03.04.0043
THERMOCOUPLE - 500MM (WAS 3.2.1100450) | In Stock | 15.99 | |
| 32 | 1.06.03.04.0007
RAPID BURNER DIVIDER (WAS 1.6.2220215-TH) | In Stock | 12.99 | |
| 33 | 1.01.03.03.0034
RAPID WATER TRAY | Low Stock | 8.99 | |
| 34 | 1.10.03.04.0005
GASKET | In Stock | 8.99 | |
| 35 | 1.06.03.05.0037
INNER RING BURNER CAP (WAS 1.6.2160022-T | In Stock | 8.99 | |
| 36 | 1.06.03.05.0033
OUTER RING BURNER CAP (WAS 1.6.2150022-TH) | In Stock | 8.99 | |
| 37 | 1.06.03.04.0017
FLAME SPREADER (WAS 1.6.2420215-TH) | In Stock | 10.99 | |
| 38 | 1.06.03.03.0019
1 CUP | In Stock | 10.99 | |
| 39 | 1.01.03.03.0018
1# TRIPLE RING WATER TRAY | In Stock | 9.99 | |
| 40 | 1.10.03.04.0002
1# GASKET | In Stock | 8.99 | |
| 41 | 1.01.03.01.0012
KY03 GLASS CHASSIS | Not Available | ||
| 42 | 2.01.03.01.0008
GLASS PANEL ASSEMBLY | Low Stock | Contact Us | |
| 43 | 1.06.03.07.0109
CAST IRON HOB LEFT | Low Stock | Contact Us | |
| 44 | 1.06.03.07.0110
MIDDLE CAST IRON HOB | Low Stock | Contact Us | |
| 45 | 1.06.03.07.0111
RIGHT CAST IRON HOB | Low Stock | Contact Us | |
| 46 | 1.04.03.03.0023
IGNITION ELECTRODE - 250MM (WAS 3.2.3000 | In Stock | Contact Us | |
| 47 | 1.04.03.04.0012
THERMOCOUPLE - 350MM | In Stock | 15.99 | |
| 48 | 1.04.03.03.0035
IGNITION ELECTRODE - 500MM (WAS 3.2.100050) | In Stock | 10.99 | |
| 49 | 1.06.03.06.0052
NG NOZZLE 1.27 | In Stock | Contact Us | |
| 50 | 1.04.03.05.0014
IMPULSIVE IGNITION DEVICE (WAS 3.4.1270005) | Low Stock | 9.99 | |
| 51-A | 1.02.03.10.0011
JUNCTION BOX - CABLE CLAMP | Low Stock | 3.99 | |
| 51-B | 1.02.03.10.0009
JUNCTION BOX - BASE | In Stock | 10.99 | |
| 51-C | 1.02.03.10.0010
JUNCTION BOX - COVER | In Stock | 3.99 | |
| 52-A | 1.06.03.06.0036
LPG NOZZLE 0.88 | In Stock | 3.99 | |
| 52-B | 1.06.03.06.0033
LPG NOZZLE 0.69 (WAS 1.8.1010069) | In Stock | 3.99 | |
| 52-C | 1.06.03.06.0029
LPG NOZZLE 0.51 (WAS 1.8.1010051) | In Stock | 3.99 | |
| 52-D | 1.03.03.06.0039
LPG NOZZLE 0.94 | Not Available | ||
| 53 | 1.11.03.04.0003
HOB MOUNTING GASKET (WAS 5.6.0000002) | In Stock | 5.99 | |
| 54-A | 1.06.03.10.0024
90 DEG ELBOW HALF INCH MALE TO FEMALE (WAS 1.9.0000003) | In Stock | 4.99 | |
| 54-B | 1.10.03.03.0001
PACKING WASHER (WAS 4.2.0000001) | Low Stock | 2.99 | |
| 55 | 1.01.03.10.0008
MOUNTING CLAMPS AND SCREWS (WAS 1.3.0000004) | In Stock | 9.99 | |
Product Design
- Type: Built-in Gas Hob
- Size: 70cm
- Number of Zones: 5
- Finish: Black Glass
- Controls: Rotary Knobs
- Pan Supports: Cast Iron
- Ignition Type: Automatic Ignition
- Safety Feature: Flame Safety Device (FSD)
- LPG Convertible: Yes (LPG Conversion Kit Included)
- Wok Burner: Yes
- Dimensions: H100 x W700 x D500 mm
Technical Specifications
Number of Burners
5
5
Pan Supports
Cast Iron
Cast Iron
Flame Failure Device
Yes
Yes
Control Location
Front
Front
Indicator Light
Auto Ignition
Yes
Yes
Wok Burner
Yes
Yes
LPG Kit Included
Yes
Yes
Cut Out Size
555 x 475mm
555 x 475mm
Description
This 70cm 5 burner gas on glass hob combines stunning design with high-performance functionality to enhance your cooking experience. Perfect for all kitchens, this sleek black glass hob offers precise control and superior cooking power.
Featuring a stylish black glass surface, it’s easy to clean and adds a sophisticated touch to any kitchen. With five cooking zones and ergonomic knob controls, you have complete control over your cooking.
It includes a powerful wok burner for high-heat cooking, durable cast iron pan supports for stability, and automatic ignition with a flame safety device (FSD) for reliable and safe operation. LPG convertible, with a conversion kit included for versatile installation.
Measuring H100 x W700 x D500 mm, this built-in gas hob delivers exceptional performance and sleek aesthetics for every cooking style.
